MTL SD55 Surge Protection Devices SPD SD55 Safe Surge Arrest
MTL SD55 Surge Protection Devices SPD SD55 Safe Surge Arresters Arrived
Features of MTL SD55 Surge Protection Devices SPD SD55 Safe Surge Arresters Arrived
MTL SD range
Ultra-slim user-friendly devices for protecting electronic equipment and systems against surges on signal and I/O cabling
• Range of ATEX Certified intrinsically safe surge protectors
• Ultra-slim space-saving design;easy installation
• Multistage hybrid protection circuitry – 20kA maximum surge current
• Range of voltage ratings – to suit all process I/O applications
• High bandwidth, low resistance, RTD, PSTN and 3-wire transmitter versions available
• 10 year product warranty
Overview of MTL SD55 Surge Protection Devices SPD SD55 Safe Surge Arresters Arrived
The SD range is a series of surge protection devices combine unparalleled packing densities, application versatility, proven reliable hybrid circuitry, simple installation and optional ‘loop disconnect’ facilities – features which make the range the ultimate surge protection solution for process equipment, I/O systems and communications networks.
The exceptionally high packing densities are the consequence of an ultra slim ‘footprint’ for individual modules which can thus‘double-up’ as feedback terminals. Each module provides full hybrid surge protection for 2 and 3 wire loop protection.
MTL SD55 Surge Protection Devices SPD SD55 Safe Surge Arresters Arrived
Modules with a comprehensive range of voltage ratings cover all process related signals such as RTDs, THCs, 4 to 20mA loops, telemetry outstations, shut-down systems and fire and gas detectors.
Optional ‘loop disconnect’, is a feature which allows commissioning and maintenance to be carried out without removal of the surge protection device. This facility is provided by the SD07, SD16, SD32 and SD55 units. In addition, a third connection on the field and safe side of the protector is provided in order to terminate screens safely
MTL SD55 Surge Protection Devices SPD SD55 Safe Surge Arresters Arrived
For three wire applications the specially designed SDRTD (Resistance Temperature Detector) and the SD32T3, (for separately powered 4-20mA loops) provide full 3-wire protection in a single compact unit. The recommended choice for the protection of 3-wire pressure transducers on low power circuits is the SD07R3.
MTL SD55 Surge Protection Devices SPD SD55 Safe Surge Arresters Arrived
For higher bandwidth applications, the SDR range has been developed to meet the demands of today’s highest speed communication systems.
120V and 240V AC versions are available for I/O and power supplies up to three Amps of load current and telephone networks can be protected by the SDPSTN.
MTL SD55 Surge Protection Devices SPD SD55 Safe Surge Arresters Arrived
MTL SD55 Surge Protection Devices SPD SD55 Safe Surge Arresters Arrived
One simple manual operation clamps modules securely onto DIN rail, which automatically provides the essential high-integrity earth connection.
‘Top-hat’ (T-section) DIN rail is generally suitable for mounting SD modules although for adverse environments, a specially-plated version is available. A comprehensive range of mounting and earthing accessories can also be supplied.
MTL SD55 Surge Protection Devices SPD SD55 Safe Surge Arresters Arrived
Analogue inputs (high-level)
2-wire transmitters, 4-20mA, conventional and smart
The SPDs recommended for use with‘conventional’ and ‘smart’ 4-20mA transmitters (fed by a well-regulated supply) are the SD32 and SD55, the choice depending upon the maximum working voltage of the system (32V and 55V respectively). The diagram illustrates a prime example of an application for which the fuse/disconnect facility is particularly useful, however, both models are available in ‘X’ versions without the optional fuse/disconnect feature.
MTL SD55 Surge Protection Devices SPD SD55 Safe Surge Arresters Arrived
Analogue inputs (low-level)
RTDs
These applications are best served using the SDRTD. For optimum accuracy, the energising current should be chosen to ensure the voltage across the RTD does not exceed 1V over the full measurement range. When using a PT100 device, we recommend an energising current of 1mA.
MTL SD55 Surge Protection Devices SPD SD55 Safe Surge Arresters Arrived
Photocells, THCs, mV sources and turbine flowmeters
The SD07 or SD16 (depending upon the operational voltage) are the favoured choices for this application. SD07X and SD16X are also suitable.
MTL SD55 Surge Protection Devices SPD SD55 Safe Surge Arresters Arrived
Analogue outputs
Controller outputs (I/P converters)
For this application, the recommendations are the SD16, SD32 and SD55 (and the equivalent‘X’ versions), the final choice depending upon the operating voltage.
MTL SD55 Surge Protection Devices SPD SD55 Safe Surge Arresters Arrived
Digital (on/off) inputs
Switches
Suitable SPDs for switches include the SD07, SD16, SD32 and SD55 modules – the choice depending upon the operating voltage of the system. The ‘X’ versions of these are also suitable.
MTL SD55 Surge Protection Devices SPD SD55 Safe Surge Arresters Arrived
Digital (on/off) outputsAlarms, LEDs, solenoid valves, etc
Alarms, LEDs, solenoid valves, etc
The recommended choice for this application is the SD32 or SD32X.
MTL SD55 Surge Protection Devices SPD SD55 Safe Surge Arresters Arrived
Telemetry (PSTN)
Telemetry outstations
The SDPSTN has been designed specifically for the protection of signals transmitted on public switched telephone networks.
MTL SD55 Surge Protection Devices SPD SD55 Safe Surge Arresters Arrived
AC supplied equipment
PLC, I/O systems
For systems on 110-120V ac, the SD150X is the recommended choice and for 220-240V ac systems, the SD275X is recommended.
Technical Data of MTL SD55 Surge Protection Devices SPD SD55 Safe Surge Arresters Arrived
All figures typical at 77°F (25°C) unless
otherwise stated
Protection
Full hybrid line to line
Each line to screen/ground
Max discharge surge current (Imax) (8/20µs)
20kA (8/20µs)
6.5kA (SD150X and SD275X only)
MTL SD55 Surge Protection Devices SPD SD55 Safe Surge Arresters Arrived
Nominal discharge surge current (isn) 3kA (8/20µs)
Lightning impulse current (Iimp) (10/350µs)
2.8kA
1.0kA (SD150X and SD275X only)
Response time <1ns
RTD resistance range (SDRTD) 10 to 1500
MTL SD55 Surge Protection Devices SPD SD55 Safe Surge Arresters Arrived
Degradation accuracy (SDRTD at 1mA)
0.1% (RTD resistance > 100 )
0.1W (RTD resistance < 100 )
Ambient temperature
–40°C to +80°C / -40°F to 176°F storage
–40°C to +80°C / -40°F to 176°F working
For IS working applications:
Pi = 1.0W (–30°C to +75°C / -22°F to 167°F)
Pi = 1.2W (–30°C to +60°C / -22°F to 140°F)
Pi = 1.3W (–30°C to +40°C / -22°F to 104°F)
MTL SD55 Surge Protection Devices SPD SD55 Safe Surge Arresters Arrived
Humidity 5 to 95% RH (non-condensing)
Category tested A2, B2, C1, C2, C3
Overstressed fault mode in=3kA
12kA
9kA (SD150X and SD275X only)
Impulse durability (8/20µs)
10kA
6.5kA (SD150X and SD275X only)
Terminals 2.5mm2(12 AWG)
Mounting T-section DIN-rail 35 x 7.5 or 35 x 15mm rail(1.38” x 0.3” x 0.6”)
MTL SD55 Surge Protection Devices SPD SD55 Safe Surge Arresters Arrived
Weight 70g approximately (2.5oz)
Case flammability UL94 V-2
AC durability 1Arms, 5T
MTL SD55 Surge Protection Devices SPD SD55 Safe Surge Arresters Arrived
Service conditions
80kPa - 160kPa
5% - 95% RH
EMC compliance
To Generic Immunity Standards,
EN 61326-1, part 2 for industrial
environments
R&TTE compliance
EN 61326-1, EN 41003 : 1999
EN 60950 - 1 : 2006
(not applicable to SD150X and SD275X)
LVD compliance
SD150X & SD275X
EN 60950 - 1 : 2006, EN 61010 : 2010
SDPST
EN 41003 : 1999
IEC compliance
EN 61643-21:2001
ANSI/IEEE testing
C62.41-1-2002
C62.41-2-2002
C62.45-2002
Ordering Models of MTL SD55 Surge Protection Devices SPD SD55 Safe Surge Arresters Arrived
MTL SD16R
SD series
SD07
SD16
SD32
SD55
SD07R
SD16R
SD32R
SD55R
SD07X
SD16X
SD32X
SD55X
SD32T3
SD07R3
SD16R3
SD32R3
SD55R3
SDRTD
SDPSTN
SD150X
SD275X
MTL SD55 Surge Protection Devices SPD SD55 Safe Surge Arresters Arrived
MTL7706+
MTL7707+
MTL7707P+
MTL7710-
MTL7710+
MTL7710P+
MTL7715+
MTL7715P+
MTL7722-
MTL7722+
MTL7728-
MTL7728+
MTL7728AC
MTL7728P+
MTL7729P+
MTL7741
MTL7742
MTL7743
MTL7744
MTL7745
MTL7751AC
MTL7755AC
MTL7756AC
MTL7758-
MTL7758+
MTL7760AC
MTL7761AC
MTL7761PAC
MTL7764-
MTL7764+
MTL7764AC
MTL7765AC
MTL7766AC
MTL7766PAC
MTL7767+
MTL7768+
MTL7772AC
MTL7778AC
MTL7779+
MTL7787-
MTL7787+
MTL7787P+
MTL7788+
MTL7788R+
MTL7789+
MTL7796-
MTL7796+
MTL7798
MTL7799
Ordering Codes of MTL SD55 Surge Protection Devices SPD SD55 Safe Surge Arresters Arrived
