Yokogawa AAI543-H50/A4S00 Analog Output Module with HART In Stock





​

Description

AAI141-H Analog Input Module (Current Input) 16-channel, 4 to 20 mA, non-isolated

AAB141-H Analog Input Module (Voltage/current Input) 16-channel, 1 to 5 V/4 to 20 mA, non-isolated

AAI841-H Analog I/O Module (Current I/O) 8-channel input/8-channel output, 4 to 20 mA, non-isolated

AAB842-H Analog I/O Module

(Voltage/current Input, Current Output)

8-channel input/8-channel output, 1 to 5 V/4 to 20 mA input,

4 to 20 mA output, non-isolated

AAI135-H Analog Input Module (Current Input) 8-channel, 4 to 20 mA, isolated channels

AAI835-H Analog I/O Module (Current I/O) 4-channel input/4-channel output, 4 to 20 mA, isolated channels

AAI143-H Analog Input Module (Current Input) 16-channel, 4 to 20 mA, isolated

AAI543-H Analog Output Module (Current Output) 16-channel, 4 to 20 mA, isolated







MODEL AND SUFFIX CODES
		Description
Model	AAI141	Analog Input Module (4 to 20 mA, 16-channel, Non-Isolated)
Suffix Codes	-S	Standard type
	-H	With digital communication (HART protocol)
	5	With no explosion protection
	E	With explosion protection
	0	Basic type
	3	With ISA Standard G3 option and temperature (-20 to 70 °C) option
Option Codes	/K4A00	With KS Cable Interface Adapter [Model: ATK4A-00]
	/A4S00	With Pressure Clamp Terminal Block for Analog [Model: ATA4S-00]
	/A4S10	With Pressure Clamp Terminal Block for Analog (surge absorber) [Model: ATA4S-10]
	/A4D00	With Dual Pressure Clamp Terminal Block for Analog [Model: ATA4D-00]
	/A4D10	With Dual Pressure Clamp Terminal Block for Analog (surge absorber) [Model: ATA4D-10]
	/CCC01	With Connector Cover for MIL Cable [Model: ACCC01]
		Description
Model	AAV141	Analog Input Module (1 to 5 V, 16-channel, Non-Isolated)
Suffix Codes	-S	Standard type
	5	With no explosion protection
	E	With explosion protection
	0	Basic type
	3	With ISA Standard G3 option and temperature (-20 to 70 °C) option
Option Codes	/K4A00	With KS Cable Interface Adapter [Model: ATK4A-00]
	/A4S00	With Pressure Clamp Terminal Block for Analog [Model: ATA4S-00]
	/A4S10	With Pressure Clamp Terminal Block for Analog (surge absorber) [Model: ATA4S-10]
	/A4D00	With Dual Pressure Clamp Terminal Block for Analog [Model: ATA4D-00]
	/A4D10	With Dual Pressure Clamp Terminal Block for Analog (surge absorber) [Model: ATA4D-10]
	/CCC01	With Connector Cover for MIL Cable [Model: ACCC01]
		Description
Model	AAV142	Analog Input Module (-10 to +10 V, 16-channel, Non-Isolated)
Suffix Codes	-S	Standard type
	5	With no explosion protection
	E	With explosion protection
	0	Basic type
	3	With ISA Standard G3 option and temperature (-20 to 70 °C) option
Option Codes	/K4A00	With KS Cable Interface Adapter [Model: ATK4A-00]
	/A4S00	With Pressure Clamp Terminal Block for Analog [Model: ATA4S-00]
	/A4S10	With Pressure Clamp Terminal Block for Analog (surge absorber) [Model: ATA4S-10]
	/A4D00	With Dual Pressure Clamp Terminal Block for Analog [Model: ATA4D-00]
	/A4D10	With Dual Pressure Clamp Terminal Block for Analog (surge absorber) [Model: ATA4D-10]
	/CCC01	With Connector Cover for MIL Cable [Model: ACCC01]
		Description
Model	AAB141	Analog Input Module (1 to 5 V/4 to 20 mA, 16-channel, Non-Isolated)
Suffix Codes	-H	With digital communication (HART protocol)
	5	With no explosion protection
	E	With explosion protection
	0	Basic type
	3	With ISA Standard G3 option and temperature (-20 to 70 °C) option
Option Codes	/K4A00	With KS Cable Interface Adapter [Model: ATK4A-00]
All Rights Reserved. Copyright © 2011, Yokogawa Electric Corporation                                                                     GS 33K50F60-50E    Apr. 1, 2013-00
		Description
Model	AAI841	Analog I/O Module (4 to 20 mAinput , 4 to 20 mA output, 8-channel input/8-channel output, Non-Isolated)
Suffix Codes	-S	Standard type
	-H	With digital communication (HART protocol)
	5	With no explosion protection
	E	With explosion protection
	0	Basic type
	3	With ISA Standard G3 option and temperature (-20 to 70 °C) option
Option Codes	/K4A00	With KS Cable Interface Adapter [Model : ATK4A-00]
	/A4S00	With Pressure Clamp Terminal Block for Analog [Model : ATA4S-00]
	/A4S10	With Pressure Clamp Terminal Block for Analog (surge absorber) [Model : ATA4S-10]
	/A4D00	With Dual Pressure Clamp Terminal Block for Analog [Model : ATA4D-00]
	/A4D10	With Dual Pressure Clamp Terminal Block for Analog (surge absorber) [Model : ATA4D-10]
	/CCC01	With Connector Cover for MIL Cable [Model : ACCC01]
		Description
Model	AAB841	Analog I/O Module (1 to 5 V input, 4 to 20 mA output, 8-channel input/8-channel output, Non-Isolated)
Suffix Codes	-S	Standard type
	5	With no explosion protection
	E	With explosion protection
	0	Basic type
	3	With ISA Standard G3 option and temperature (-20 to 70 °C) option
Option Codes	/K4A00	With KS Cable Interface Adapter [Model : ATK4A-00]
	/M4A00	With MAC2 Compatible Adapter [Model : ATM4A-00]
	/V4A00	With VM2 Compatible Adapter [Model : ATV4A-00] (*1)
	/A4S00	With Pressure Clamp Terminal Block for Analog [Model : ATA4S-00]
	/A4S10	With Pressure Clamp Terminal Block for Analog (surge absorber) [Model : ATA4S-10]
	/A4D00	With Dual Pressure Clamp Terminal Block for Analog [Model : ATA4D-00]
	/A4D10	With Dual Pressure Clamp Terminal Block for Analog (surge absorber) [Model : ATA4D-10]
	/CCC01	With Connector Cover for MIL Cable [Model : ACCC01]
*1:     When using this adapter, 4 to 20 mA output (8-channel) of AAB841 varies to 1 to 5 V output.
		Description
Model	AAB842	Analog I/O Module (1 to 5 V/4 to 20 mAinput, 4 to 20 mA output, 8-channel input/8-channel output, Non-Isolated)
Suffix Codes	-H	With digital communication (HART protocol)
	5	With no explosion protection
	E	With explosion protection
	0	Basic type
	3	With ISA Standard G3 option and temperature (-20 to 70 °C) option
Option Codes	/M4A00	With MAC2 Compatible Adapter [Model : ATM4A-00]
	/V4A00	With VM2 Compatible Adapter [Model : ATV4A-00] (*1)
*1:     When using this adapter, 4 to 20 mA output (8-channel) of AAB842 varies to 1 to 5 V output.
		Description
Model	AAV542	Analog Output Module (-10 to +10 V, 16-channel, Non-Isolated)
Suffix Codes	-S	Standard Type
	5	With no explosion protection
	E	With explosion protection
	0	Basic type
	3	With ISA Standard G3 option and temperature (-20 to 70 °C) option
Option Codes	/K4A00	With KS Cable Interface Adapter [Model : ATK4A-00]
	/A4S00	With Pressure Clamp Terminal Block for Analog [Model : ATA4S-00]
	/A4S10	With Pressure Clamp Terminal Block for Analog (surge absorber) [Model : ATA4S-10]
	/A4D00	With Dual Pressure Clamp Terminal Block for Analog [Model : ATA4D-00]
	/A4D10	With Dual Pressure Clamp Terminal Block for Analog (surge absorber) [Model : ATA4D-10]
	/CCC01	With Connector Cover for MIL Cable [Model : ACCC01]
All Rights Reserved. Copyright © 2011, Yokogawa Electric Corporation                                                                     GS 33K50F60-50E    Apr. 1, 2013-00
		Description
Model	AAI143	Analog Input Module (4 to 20 mA, 16-channel, Isolated)
Suffix Codes	-S	Standard type
	-H	With digital communication (HART protocol)
	5	With no explosion protection
	E	With explosion protection
	0	Basic type
	3	With ISA Standard G3 option and temperature (-20 to 70 °C) option
Option Codes	/K4A00	With KS Cable Interface Adapter (For connecting AEA4DTerminal Board) [Model: ATK4A-00]
	/A4S00	With Pressure Clamp Terminal Block [Model: ATA4S-00]
	/A4S10	With Pressure Clamp Terminal Block (surge absorber) [Model: ATA4S-10]
	/A4D00	With Dual Pressure Clamp Terminal Block [Model: ATA4D-00]
	/A4D10	With Dual Pressure Clamp Terminal Block (surge absorber) [Model: ATA4D-10]
	/CCC01	With Connector Cover for MIL Cable [Model: ACCC01]
		Description
Model	AAI543	Analog Output Module (4 to 20 mA, 16-channel, Isolated)
Suffix Codes	-S	Standard type
	-H	With digital communication (HART protocol)
	5	Standard switch-over response in redundant configuration with no explosion protection(*1)
	6	Fast switch-over response in redundant configuration with no explosion protection(*2)
	E	Standard switch-over response in redundant configuration with explosion protection(*1)
	F	Fast switch-over response in redundant configuration with explosion protection(*2)
	0	Basic type
	1	With ISA Standard G3 option
	3	With ISA Standard G3 option and temperature (-20 to 70 °C) option
Option Codes	/K4A00	With KS Cable Interface Adapter (For connecting AEA4DTerminal Board) [Model: ATK4A-00]
	/A4S00	With Pressure Clamp Terminal Block [Model: ATA4S-00]
	/A4S10	With Pressure Clamp Terminal Block (surge absorber) [Model: ATA4S-10]
	/A4D00	With Dual Pressure Clamp Terminal Block [Model: ATA4D-00]
	/A4D10	With Dual Pressure Clamp Terminal Block (surge absorber) [Model: ATA4D-10]
	/CCC01	With Connector Cover for MIL Cable [Model: ACCC01]
*1:      If “standard switch-over response in redundant configuration” is selected, “basic type” or “with ISA Standard G3 option and                temperature (-20 to 70 °C) option” may be specified.
*2:      If “fast switch-over response in redundant configuration” is selected, “basic type” or “with ISA Standard G3 option” may be                specified.
		Description
Model	AAV144	Analog Input Module (-10 to +10 V, 16-channel, Isolated)
Suffix Codes	-S	Standard type
	5	With no explosion protection
	E	With explosion protection
	0	Basic type
	3	With ISA Standard G3 option and temperature (-20 to 70 °C) option
Option Codes	/K4A00	With KS Cable Interface Adapter [Model: ATK4A-00]
	/A4S00	With Pressure Clamp Terminal Block for Analog [Model: ATA4S-00]
	/A4S10	With Pressure Clamp Terminal Block for Analog (surge absorber) [Model: ATA4S-10]
	/A4D00	With Dual Pressure Clamp Terminal Block for Analog [Model: ATA4D-00]
	/A4D10	With Dual Pressure Clamp Terminal Block for Analog (surge absorber) [Model: ATA4D-10]
	/CCC01	With Connector Cover for MIL Cable [Model: ACCC01]
All Rights Reserved. Copyright © 2011, Yokogawa Electric Corporation                                                                     GS 33K50F60-50E    Apr. 1, 2013-00
		Description
Model	AAV544	Analog Output Module (-10 to +10 V, 16-channel, Isolated)
Suffix Codes	-S	Standard Type
	5	With no explosion protection
	E	With explosion protection
	0	Basic type
	3	With ISA Standard G3 option and temperature (-20 to 70 °C) option
Option Codes	/K4A00	With KS Cable Interface Adapter [Model : ATK4A-00]
	/A4S00	With Pressure Clamp Terminal Block for Analog [Model : ATA4S-00]
	/A4S10	With Pressure Clamp Terminal Block for Analog (surge absorber) [Model : ATA4S-10]
	/A4D00	With Dual Pressure Clamp Terminal Block for Analog [Model : ATA4D-00]
	/A4D10	With Dual Pressure Clamp Terminal Block for Analog (surge absorber) [Model : ATA4D-10]
	/CCC01	With Connector Cover for MIL Cable [Model : ACCC01]
		Description
Model	AAT141	TC/mV Input Module (16-channel, Isolated)
Suffix Codes	-S	Standard type
	5	With no explosion protection
	E	With explosion protection
	0	Basic type
	3	With ISA Standard G3 option and temperature (-20 to 70 °C) option
Option Codes	/T4S00	With Pressure Clamp Terminal Block for Thermocouple/mV [Model: ATT4S-00]
	/T4S10	With Pressure Clamp Terminal Block for Thermocouple/mV (surge absorber) [Model: ATT4S-10]
	/T4D00	With Dual Pressure Clamp Terminal Block for Thermocouple/mV [Model: ATT4D-00]
	/T4D10	With Dual Pressure Clamp Terminal Block for Thermocouple/mV (surge absorber) [Model: ATT4D-10]
	/CCC01	With Connector Cover for MIL Cable [Model: ACCC01]
		Description
Model	AAR181	RTD Input Module (12-channel, Isolated)
Suffix Codes	-S	Standard type
	5	With no explosion protection
	E	With explosion protection
	0	Basic type
	3	With ISA Standard G3 option and temperature (-20 to 70 °C) option
Option Codes	/R8S00	With Pressure Clamp Terminal Block for RTD [Model: ATR8S-00]
	/R8S10	With Pressure Clamp Terminal Block for RTD (surge absorber) [Model: ATR8S-10]
	/R8D00	With Dual Pressure Clamp Terminal Block for RTD [Model: ATR8D-00]
	/R8D10	With Dual Pressure Clamp Terminal Block for RTD (surge absorber) [Model: ATR8D-10]
	/CCC01	With Connector Cover for MIL Cable [Model: ACCC01]
		Description
Model	AAI135	Analog Input Module (4 to 20 mA, 8-channel, Isolated channels)
Suffix Codes	-S	Standard type
	-H	With digital communication (HART protocol)
	5	With no explosion protection
	E	With explosion protection
	0	Basic type
	3	With ISA Standard G3 option and temperature (-20 to 70 °C) option
Option Codes	/13A00	With KS Cable Interface Adapter [Model: ATI3A-00]
	/K4A00	With KS Cable Interface Adapter [Model: ATK4A-00]
	/13S00	With Pressure Clamp Terminal Block for Isolated Analog [Model: ATI3S-00]
	/13S10	With Pressure Clamp Terminal Block for Isolated Analog (surge absorber) [Model: ATI3S-10]
	/13D00	With Dual Pressure Clamp Terminal Block for Isolated Analog [Model: ATI3D-00]
	/13D10	With Dual Pressure Clamp Terminal Block for Isolated Analog (surge absorber) [Model: ATI3D-10]
	/CCC01	With Connector Cover for MIL Cable [Model: ACCC01]
All Rights Reserved. Copyright © 2011, Yokogawa Electric Corporation                                                                     GS 33K50F60-50E    Apr. 1, 2013-00
		Description
Model	AAI835	Analog I/O Module (4 to 20 mA, 4-channel input/4-channel output, Isolated channels)
Suffix Codes	-S	Standard type
	-H	With digital communication (HART protocol)
	5	With no explosion protection
	E	With explosion protection
	0	Basic type
	3	With ISA Standard G3 option and temperature (-20 to 70 °C) option
Option Codes	/B3A00	With KS Cable Interface Adapter [Model: ATB3A-00]
	/K4A00	With KS Cable Interface Adapter [Model: ATK4A-00]
	/13S00	With Pressure Clamp Terminal Block for Isolated Analog [Model: ATI3S-00]
	/13S10	With Pressure Clamp Terminal Block for Isolated Analog (surge absorber) [Model: ATI3S-10]
	/13D00	With Dual Pressure Clamp Terminal Block for Isolated Analog [Model: ATI3D-00]
	/13D10	With Dual Pressure Clamp Terminal Block for Isolated Analog (surge absorber) [Model: ATI3D-10]
	/CCC01	With Connector Cover for MIL Cable [Model: ACCC01]
		Description
Model	AAT145	TC/mV Input Module (16-channel, Isolated channels)
Suffix Codes	-S	Standard type
	5	With no explosion protection
	E	With explosion protection
	0	Basic type
	3	With ISA Standard G3 option and temperature (-20 to 70 °C) option
		Description
Model	AAR145	RTD/POT Input Module (16-channel, Isolated channels)
Suffix Codes	-S	Standard type
	5	With no explosion protection
	E	With explosion protection
	0	Basic type
	3	With ISA Standard G3 option and temperature (-20 to 70 °C) option
		Description
Model	AAP135	Pulse Input Module (8-channel, Pulse count, 0 to 10 kHz, Isolated channels)
Suffix Codes	-S	Standard type
	5	With no explosion protection
	E	With explosion protection
	0	Basic type
	3	With ISA Standard G3 option and temperature (-20 to 70 °C) option
Option Codes	/13A00	With KS Cable Interface Adapter [Model: ATI3A-00]
	/K4A00	With KS Cable Interface Adapter [Model: ATK4A-00]
	/13S00	With Pressure Clamp Terminal Block for Pulse [Model: ATI3S-00]
	/13S10	With Pressure Clamp Terminal Block for Pulse (surge absorber) [Model: ATI3S-10]
	/13D00	With Dual Pressure Clamp Terminal Block for Pulse [Model: ATI3D-00]
	/13D10	With Dual Pressure Clamp Terminal Block for Pulse (surge absorber) [Model: ATI3D-10]
	/CCC01	With Connector Cover for MIL Cable [Model: ACCC01]
		Description
Model	AAP149	Pulse Input Module PM1 compatible (16-channel, Pulse count, 0 to 6 kHz, Non-Isolated)
Suffix Codes	-S	Standard type
	0	Always 0
	0	Basic type
	1	With ISA Standard G3 option
All Rights Reserved. Copyright © 2011, Yokogawa Electric Corporation                                                                     GS 33K50F60-50E    Apr. 1, 2013-00
		Description
Model	AAP849	Pulse Input Module/ Analog Output Module for compatible PAC (Pulse count Input, 4 to 20 mA output, 8-channel input / 8-channel output, Non-Isolated)
Suffix Codes	-S	Standard type
	0	Always 0
	0	Basic type
	1	With ISA Standard G3 option
n ORDERING INFORMATION
Specify the model and suffix codes.
For selecting the right products for explosion protection, please refer to TI 33Q01J30-01E without fail.

More Yokogawa Products for your choice:

СР471-00	AAI543S,complete model:AAI543-S50	AXG050-GG000BE4AL112B AXG4A-AXG050-GG000BE4AL112B-NNNNN+AXG4A-G000121JA12/CH	GRVSW-668FA	NFSB100-S50	SPW482-53  replacement  SPW482-E3
AAI143-H50/A4S00	AAI543-S00	AXG100-CAKJ2BA1AL112B-1JP21/EC  AXG100-CANF2BA1AL112B-1JP21/CH	GRVSW-669FA	OXYGOLD G 120	SPW482-53  replacement SPW482-E3
AAI143-S00, replaced by:AAI143-S50	AAI543-S50	AXG200-GA000CE2AL112B-1JA11  AXG200-GA000CE2AL112B-1JA12/CH	GRVSW-670FA	PFCD-E5521	SPW482-53 or SPW482-13   replacement  SPW482-E3
AAI543-H50/K4A00	AAI543-S50/A4S10 with ATA4S-10	AXW20-GA000BA1UH214B-2JE11/GRH   AXW200-GA000BA1UH214B-2JE12/GRH/CH	GRVSW-671FA	PH8AX-P-A/KCLP/EP	SPW482-E3
AAI543-S00  replacement AAI543-S50	AAI543-S50/A4S10,  ATA4S-10	CA450-E	GRVSW-672FA	PH8EFP-10-TN-TT1-N-Е/PF	SSB401-13
AAT145-S00	AAI543-S50/A4S10,  ATA4S-10	CL360	GRVSW-673FA	PH8EHP-03-TN-TT3-N-E*А	SSB401-53
AIP601	AAI543-S50/A4S11, correct model:AAI543-S50/A4S10	CP401-10	HHR-21AHF2A1	PSR-PC50-1NO-1DO-24DC-SC	SSB401-53 SSB401-13
EJA110A-ELS4A-27DC/KS2	AAI543-S50/K4A00	CP451-10	HHR-30HF5G1	PW301	STA4D
EJA110A-EMS4B-89DB	AAI841-S50/K4A00	CP451-10  replacement  CP451-50	ISC40G-TG-T1-03/TFD/PH03	PW482-10,upgraded model: PW482-50	STA4S
EJA110A-EMS5B-99NB/KU2/D4/C3/N5/N4/Z	AAl141-H50/K4A00  replacement AAI141-H00/K4A00	CP451-10-S2	K1520VA	PW482-50	STARDOM  NFAI841
EJA110A-EMS5B-99NB/KU2/D4/C3/N5/N4/Z+990.28	AAl141-S50/K4A00	CP451-50	K9034BA	PW482-51	T9070CB
EJA110A-EMS5B-99NN/KU2	AAl841-S50/K4A00	CP461-10	K9034BB	PW482-51   PW482-50	T9070CK
EJA110E-JMS5J-714ED/GS11/D4/VR	AAM10	CP461-50	K9034DN	RAMC01-A1SS-6151-E90424/B1 RAMC01-A1SS-61S1-E90424/B1/CN	UM-2KS40/16AIO/RS/SO225 2319838
EJA110E-JMSWJ-914EB/GS1/VR	AAP135-S00	CP461-50 S1	K9034DP	RAMC01-D4SS-54L1-H0424/A13/D11/GS1/VE WITH PAP-11 MON EN1092-1 Form B1 DN 15 PN 40CT.20	UT350L
EJA530A-EBS7N-04NE/KS2/QR	AAR145-S50	CP461-51	K9142TN	RAMC03-A1PF-6242-E90424/B1 RAMC03-A1PF-62S2-E90424/B1/CN	UT351
EJA530A-EBS7N-09DF/D4/HAC	AAT145-S50	CP461-51 CP461-50	K9192QB	RAMC05-A1SS-72S5-E90424/B1 RAMC05-A1SS-72S5-E90424/B1/CN	VF701
EJA530E-JBS9N-014NL/GS1/N4/VR	AAV141-S00	CP471-00	K9192QJ	RCCT34-DH1M04D4SL/KF1/BG/QR1  replacement RCUS34S-40BD40-0C60-NF21-2-JA1/BG/CN	VF702
EJX110A-ELS4J-717ND/KS2/N4/QR	AAV144-S50/A4S10	CPY-C3-AAI141	K9193GQ	RCEG2HS-2HBD20-0E70-GF21-4-JB1/BG/VR  replacement RCEG2HS-2HBD20-0E70-GF21-4-JB1/BG/CN	VI702
EJX510A-JAS9N-019DL/GF12/N4/VR	AAV144-S50/A4S10 + ATA4S-10	CPY-C3-AAI543-HD	K9193GR	RCUP50S-25BA10-0E7J-NN00-2-JA1 RCUP50S-25BA10-0E7J-NN00-2-JA1/CN	VI702-S1
EJX530A-EAS7N-017DL/KS21/N4/QR	AAV144-S50/A4S10 + ATA4S-10	E7042BS	K9319QA	S2BN5D-121 DO	VP200-AM32/JF3/LV/GM
EJX530A-ECS8N-017NL/KS21/N4	ACM12	E7042UD	K9471UA	S2CP471-01	YCB301-C020
GRVSFP-675FA	ADCV01	EB401-10,upgraded model: EB401-50	K9477EA	S2CP471-51	YCB301-C100
K9471UA	ADM12C	EB402-10	K9634CF	S2EN402-S0001	YCB301-C100 L=1m
K9676MA	ADM52C-2	EB402-50	K9634DA	S2NN30D-430100003	YCB301-C100 L=1m
KGC-12131	ADV151-E00	EB501-10	K9634DB	S2SC70D-SA12010	YCB301-C100 L=5m  YCB301-C500 L=5m
KGC-12331	ADV151-E50	EC401-10	K9634EA	S9129FA	YCB301-C200
KGC-12342	ADV151-E50 ADV151-E00	EC401-10,discontinued  replacement EC401-50	K9676MA	S9185FA	YCB301-C300
KGC-13099	ADV151-E60/D5A00	EC401-50	K9772R	S9343FA	YCB301-C300 3m
KGC-14058	ADV151-P00	EC401-51	K9772RB	S9400UK	YCB301-С100
MRIC-32/24VDC/DPS/SC	ADV151-P00 S2	EC401-51 EC401-50	K9772RC	S9400UK 2	YG1SY01-XXW1016-E0
PFCD-E5521	ADV151-P50	EC402-50	K9772RD	S9400UK	YG1T5810-W0701E-N
S9129FA	ADV151-P50/CCC01  ADV151-P50	EC402-51	K9772RE	S9450FE	YNT511D-P42/KT
S9185FA	ADV151-P50/D5A00	EJA110A-EHS2A-27NC/KF2/QR	K9775EB	S9548FA	YUC40
SBA4D-06	ADV151-P60/B5S00	EJA110A-EHS4B-39DD/D4	K9775EC	S9757UV	YUC50
SC450G-A-A/UM	ADV161-P00	EJA110A-EMS4A-27DC/KS2/N4/QR	K9775ED	S9757UV, 2m	ZR202S-A-040-S-E-N-E-R-M-E-A/SCT
Stardom	ADV161-P50	EJA110A-EMS4B-29DD	K9775EE	SAI143-H03/A4S10, discontinued SAI143-H53/A4S10	ZR22G-015-C-C-E-R-M-E-A/C/CV/SCT
STARDOM FCN	ADV169P	EJA110A-EMS4B-99NB/KU2/C3/M11/T12/N4/D4/Z	K9802NA	SAI143-H33 SAI143-H33/PRP	ZR22G-015-S-Q-C-T-T-E-A/SV/SCT
YCB301-C020 L=0.2m	ADV169-P00	EJA110A-EMS4B-99NB/KU2/D4/C3/M11/T12/N4/D4/Z	KGC-12331	SAI143-H33,upgraded model: SAI143-H63	ZR22G-040-S-C-C-T-M-E-A
YNT511D-P42/KT	ADV169-P01	EJA110A-EMS5B-97NA/KU2/N5	KGC-12332	SAI143-H53	ZR22G-040-S-C-E-T-T-E-A
YTA110-EA4ND/KU2/N4	ADV169-P50	EJA110A-EVS5A-94DN/M01/D4/N2/N4/KU2	KGC-12355	SAI143-H53/A4S00	ZR22G-040-S-E-C-R-MEA
ANB10D-425/CU2N	ADV551-P00 ADV551-P50	EJA110E-JHS5J-914EN/GS12/VR	KGC-12356	SAI143-H63	ZR22G-040-S-E-C-R-M-E-A
MROC-32/24VDC-230VAC/DPS/AKB	ADV551-P00 S2	EJA110E-JMS5J-714ED/GS11/D4/VR	KGC-12366	SAI143-H63/A4D00	ZR22G-100-S-K-C-T-T-E-A
NFAI141-S50 S2	ADV551-P50	EJA110E-JMSWJ-914EB/GS1/VR	KS10-07 GS 33M50J10-40E	SAI143-S03 SAI143-H33 SAI143-H53 SAI143-H63	ZR22G-150-C-C-E-T-T-E-A/F1/SCT/C
NFAI841 S50 S2 NFAI841-S00	ADV551-P60/D5S00	EJA110-ELS5A	KS10-10	SAI143-S53	ZR22G-150-S-K-C-T-T-E-A
126AT5008ABC	ADV561-P50	EJA118E-JMSCG-917EB-WD23B2SW00-BA2A/GS12/N4/VR	KS10-10*A	SAI143-S53 S3	ZR22G-300-S-K-C-T-M-E-A
5102-7487-5	ADV569P	EJA210EJMS5G-919DN-EZ4B2Z0Z-B/GF12/VR/200mm/0...4250mmH2O	KS10-10А 50-50pins L=10m	SAI143-S53/A4S10	ZR22S-Q-100-C-F-E-T-T-E-A/C/CV
9548FA (HHR-21AHF2A1)	ADV569-P00	EJA310E-JLS5J-714NB/GS1/VR	KS10-10А L=10m	SAI533-Н33	ZR402G-M-E-E-A
A1BA4D-05	ADV569-P01	EJA510A-EAS7N-09NF/KS2/QR	KS10-15А L=15m	SAI533-Н53	ZR402G-M-E-E-A/HS1
A1BD5D-05	ADV569-P50	EJA510A-EAS9N-04NN/KS2/QR	KS1-10B	SAl143-H63	ZR402G-M-E-E-A-SCT
A2EE1A-T	ADV869-P00	EJA510E-JAS9N-014NL/GS1/VR	KS1-15B	SB401-10	АКВ331-М010
A2EN402-S0000	ADV869-P01	EJA530A-EAS7N-07NN/KS2	KS1-20*A	SB401-10  replacement SB401-50	АКВ331-М020
A2EN404-S0000	AEA4D-05	EJA530A-EAS7N-09EE/KS2/QR	KS1-20*B	SB401-50	Е70042UD
A2FV50D-A412000	AEP7D-25	EJA530A-EBS7N-07DE/KF2/QR	KS1-25*B/SAI143	SBA4D-06	К9034DQ
A2KLF00-1С60	AFS40D, CP345	EJA530A-EBS9N-04NN/KS2/QR	L9862AB	SBD4D	К9142TN
A2KPB00-1C62	AFV30D-A41252	EJA530A-ECS9N-04NN/KS2/QR	L9862AC	SC21-CAGC55	К9142TК
A2SAM105-H000	AFV30D-S41252	EJA530E-JBS9N-014EN/GS1/VR	L9862AD	SC25V-ALP25-120	К9192WL
A2SAM105-H000 S2	AFV30D-S41252  AFV30D-A41252	EJA530E-JCS7N-014EL/GS12/N4/VR	L9862AG	SC42-SP34	К9402UN
AAI141-H00	AIP504-10	EJA530E-JCS9N-019EL/GU12/N4/VR	M1277GH (Single Board Computer (SBC))	SC4AJ-T-AD-09-002-03-T1	К9402VG.
AAI141-H00/K4A00	AIP504-50	EJX110A-EHS4G-B9NG/KS2/D4/CA/PE3	M1282HB (Single Board Computer (SBC))	SCP451-51
AAI141-H50	AIP571	EJX110A-EHS4J-917NB/KS2/N4	MACH104-20TX-FR	SCP451-51 S1
AAI141-H50 AAI141-H00	AIP601	EJX110A-ELH5G-919NJ/KS21/N4/C3/QR	MR0-32/24VDC-220VAC/DPS/RELPOL	SCP461-51
AAI141-H50/K4A00	AIP601-S1	EJX110A-EMS4G-917DB/N4/QR	MRI -32/24VDC/DRS/RELPOL	SDV144-S13
AAI141-H50/K4A00  AAI141-H00/K4A00	AIP602-S2	EJX110A-EMS4J-917NВ/КS2/N4	MRI-32/24VDC	SDV144-S13
AAI141-H50/K4A00  AAI143-H50/K4A00	AIP827-2	EJX110A-EMS5J-819DB/KF22/QR	MRI-32/24VDC/DPS/RELPOL	SDV144-S13  replacement SDV144-S33
AAI141-S00	AIP830-101	EJX110A-EMS5J-917EB/KS21/N4	MRI-32/24VDC/DPS/RELPOL/SC	SDV144-S13/B4D00
AAI141-S50	AIP830-111/EIM	EJX110A-EMS5J-917NB/KS21/N4/QR	MRIC-32/230VAC-DC	SDV144-S13/B4D00,discontinued  replacement SDV144-S63/B4D00
AAI141-S50/K4A00	AKB331-M010/HF  AKB331-M010	EJX110A-EMSWJ-917NB/KS2/N4/QR	MRIC-32/230VAC-DC	SDV144-S33
AAI143	AKB337-15	EJX110A-EVS5G-719ED/KS2/D4/QR	MRIC-32/24VDC/DPS	SDV144-S33,upgraded model: SDV144-S63
AAI143 AAI143-H50	AKB337-M010	EJX120A-EES5G-717ND/KS21/N4/QR	MRIC-32/24VDC/DPS/AKB/RELPOL	SDV144-S53
AAI143-H00	AKB337-M020 L=20m	EJX210X-EMS5J-919DN-WA12BW00-B/OU1/N4/QR	MRIC-32/24VDC/DPS/SC	SDV144-S53
AAI143-H00 S1	ALE111 ALE111-S50	EJX510A-EBS9N-019DL/KF22/N4/QR	MRIC-32/24VDC-230VAC/DPS/AKB/RELPOL	SDV144-S53 S4
AAI143-H50	ALE111-S50	EJX530A-EAS4N-017NL/KS2/N4/QR	MRO-32/24 VDC-230VAС/DPS/RELPOL/SC	SDV144-S53/S4 /B4S00
AAI143-H50/A4S00	ALE111-S51	EJX530A-EBS4N-017NL/KS2/N4/QR	MROC-32/24VDC-230VAC/DPS	SDV144-S63
AAI143-H50/A4S10+ ATA4S-10	ALE121-S50	EJX530A-EBS4N-017NL/KS21/N4	NFAI143, complete model:NFAI143-S50	SDV531-L33
AAI143-H50/K4A00	ALE121-S50  ALR121-S50	EJX530A-EBS7N-019DN/GF12/VR	NFAI143-H50	SDV531-S23
AAI143-H53	ALP111-S01	EJX530A-EBS8N-017DL/KS21/N4/QR	NFAI143-H50, quoted advanced model: NFAI143-HE0	SDV531-S33
AAI143-H53 AAI143-H50	ALP121-S00	EJX530A-EBS8N-017NL/KS21/N4/QR	NFAI143-H50/A4AS0	SDV531-S33  replacement  SDV531-S63
AAI143S,complete model:AAI143-S50	ALR111-S50  replacement  ALR111-S00	EJX530A-ECS4N-017NL	NFAI143-H50-S1	SDV531-S33,upgraded model:SDV531-S63
AAI143-S00	ALR121-S00	EJX530A-ECS7N-019DN/KF22/N4/QR	NFAI143-HE0/A4S00	SDV531-S53
AAI143-S50	ALR121-S50	EJX530A-EСS4N-017NL/KS21/N4	NFAI143-S50 S2	SDV531-S53 S4
AAI143-S50/A4S00	ALR121-S50  replacement  ALR121-S53	ER17500V/3.6V	NFAI841	SDV531-S63
AAI143-S50/A4S00 with ATA4S-00	ANB10D-425/CU2N	F9391AM	NFAI841,complete model: NFAI841-S00	SDV541-S33
AAI143-S50/A4S00 with  ATA4S-00	ANB10D-425/CU2N/NDEL	FLXA202-DBD-CQ-P1-NN-A-N-L-A-N-NN/UM/CF4	NFAl143-H50/A4AS0	SDV541-S33,  2013
AAI143-S50/A4S10	ANB10D-425/CU2T	FLXA202-D-C-D-CQ-C1-NN-A-N-LA-N-NN	NFAP135-S50/13S00	SDV541-S53
AAI143-S50/K4A00	ANB11D-425/BU2A	FLXA202-D-C-D-CQ-P1-NN-A-N-LA-N-NN	NFBU050-S15	SDV541-S63
AAI543-H00	ANT401-50/CU1T	FLXA21-DES-EA-P1-NN-A-N-LA-N-NN/UM/CF4/TS5	NFBU200-S05  NFBU200-S01	SEA4D-06
AAI543-H00 S1	ANT401-5E,  code E  ANT401-50	FLXA21-DPD-EQ-C1-NN-A-N-LA-N-NN/UM/CF4	NFBU200-S05  replacement  NFBU200-S06	SEC401-50
AAI543-H00,upgraded model: AAI543-H50	AQ1000	FLXA402-D-B-AJ-C5-NN-A2-NR-N-N-N-NN/U	NFBU200-S05, quoted advanced model:NFBU200-S01	SEC401-51
AAI543-H00/A4S00	AQ1100A	FLZA402-A-B-AB-CI-NN-AZ-WN-N-N-N-NN/UM  FLXA402-A-B-AB-CI-NN-A2-WR-N-N-N-NN/UM	NFCB301	SEC402-51
AAI543-H00/K4A00  replacement  AAI543-H53/K4A00	AQ1100B	FU20-05-T2-NPT	NFCP100-S05	SMRI-16/230VAC/RELPOL/SC
AAI543-H00/K4A00,upgraded model: AAI543-H50/K4A00	AQ1100D	GCRV-GBARS88N0151/A100/B036	NFCP100-S05  NFCP100-S00	SMRO-16/24VDC-230VAC/RELPOL
AAI543-H50	ASI133-S00/SA3S0	GRVACA-677FA	NFCP100-S05 S3 NFCP100-S00	SNB10D-223/CU2N
AAI543-H50/A4S00	ASI533-H00/ATSA3S	GRVSFP-675FA	NFDV151,complete model:NFDV151-P60	SNB10D-223/CU2N SNB10D-425/CU2N
AAI543-H50/A4S10+ATA4S-10	ATA4S	GRVSW-660FA	NFDV151-P60 S2	SNB10D-225/CU2N
AAI543-H50/K4A00	ATD5A-00	GRVSW-660FA  replacement  Hirschmann MACH104-20TX-FR	NFDV151-P60/B5S00	SNB10D-225/CU2N ESB
AAI543-H53	ATSR3D	GRVSW-663FA	NFDV551,complete model:NFDV551-P11	SNB10D-225/CU2N/CU2T
AAI543-H53 AAI543-H50	AVR10D-Q022020	GRVSW-664FA	NFDV551-P60/D5S00	SNB10D-425/CU2N
AAI543-H53/K4A00	AXF100G-E2-AL1L-BD41-41B/QR AXG100-GA000BE2AL212B-2JA12/GRL/CH	GRVSW-665FA	NFPW426-1	SNB10D-425/CU2N or SNB10D-425/CU2T
AAI543-H60	AXFA11G-E1-41,discontinued  replacement AXG1A-G000141J012/CH	GRVSW-666FA	NFPW442-10	SPW482-13,  replacement PW482-E3
AAI543-H60/K4A00	AXG050-CAKJ2BA1AL112B-1JP21/EC  AXG050-CANF2BA1AL112B-1JP21/CH	GRVSW-667FA	NFPW442-50	SPW482-53





We mainly supply Yokogawa,Emerson, Rosemount,Fisher,Honeywell,Siemens, ABB,FLUKE, Schneider Electric, Pepperl+Fuchs,MTL,Rockwell(Allen Bradley), Hirschmann, Eaton ,Moeller,FUJI,Omron, Yaskawa,Norgren,CHINT,Hach,Weidmuller,Phoenix, SMC,Testo, ASCO,Parker,Mitsubishi, Festo,GE, CISCO,Auma,IFM,GM,Turck,MOXA, Foxboro, Krohne, Swagelok, LS, Advantech, Dwyer,Endress Hauser, Bently Nevada,Moog etc.



Contact:
