Model

AAI543

Analog Output Module (4 to 20 mA, 16-channel, Isolated)

Suffix Codes

-S

Standard type

-H

With digital communication (HART protocol)

5

Standard switch-over response in redundant configuration with no explosion protection(*1)

6

Fast switch-over response in redundant configuration with no explosion protection(*2)

E

Standard switch-over response in redundant configuration with explosion protection(*1)

F

Fast switch-over response in redundant configuration with explosion protection(*2)

0

Basic type

1

With ISA Standard G3 option

3

With ISA Standard G3 option and temperature (-20 to 70 °C) option

Option Codes

/K4A00

With KS Cable Interface Adapter (For connecting AEA4DTerminal Board) [Model: ATK4A-00]

/A4S00

With Pressure Clamp Terminal Block [Model: ATA4S-00]

/A4S10

With Pressure Clamp Terminal Block (surge absorber) [Model: ATA4S-10]

/A4D00

With Dual Pressure Clamp Terminal Block [Model: ATA4D-00]

/A4D10

With Dual Pressure Clamp Terminal Block (surge absorber) [Model: ATA4D-10]

/CCC01

With Connector Cover for MIL Cable [Model: ACCC01]

Model

AAI543-□5□/-□E□

AAI543-□6□/-□F□ (*2)

Number of output channels

16, isolated, standard switch-over

response in redundant configuration (*3)

16, isolated, fast switch-over response in redundant configuration (*3)

Output signal

4 to 20 mA

Withstanding voltage

Between output and system: 1500 VAC, for 1 minute (*4)

Allowable load resistance

0 to 750 Ω

Circuit-open detection

Less than 0.65 mA

Accuracy

±48 µA

Data update period

10 ms

Drift due to ambient temperature change

±16 µA/10 ˚C

Maximum current consumption

230 mA (5 V DC), 540 mA (24 V DC)

Weight

0.4 kg

External communication

Pressure clamp terminal, MIL connector cable, dedicated cable (KS1)

HART communication (*5)

Available
