Yokogawa EJA438E Diaphragm Sealed Gauge Pressure Transmitter

description:Yokogawa EJA438E Diaphragm Sealed Gauge Pressure Transmitters...

Inquiry

BASIC INFO

Yokogawa EJA438E Diaphragm Sealed Gauge Pressure Transmitters

The EJA-A series is Yokogawa's most successful pressure transmitter line. First released in 1991, it continues to offer high performance and high reliability for any application. With an installed base of over 4-1/2 million EJA-A transmitters worldwide, it has a proven track record that makes it a true industry workhorse.

The EJA438W is a Gauge Pressure Transmitter with a Remote Diaphragm seal attached.

It is available with a Flush Type Remote Seal (EJA438W) or an Extended Type Remote Seal (EJA438N).We have competitive price on yokogawa pressure transmitter,flowmeter,temperature transmitter,etc.The transmitter is 100% brand news and origin in Japan.

Yokogawa EJA438E Diaphragm Sealed Gauge Pressure Transmitters

Yokogawa EJA438W features include:

0.2% Accuracy

700 ms Response Time

External Zero Adjust

Yokogawa EJA438E Diaphragm Sealed Gauge Pressure Transmitters

Product Description Yokogawa EJA438E Diaphragm Sealed Gauge Pressure Transmitters

Diaphragm seal is used to prevent process medium from entering directly into the pressure-sensing assembly of the pressure transmitter. It is connected to the transmitter using capillary filled with fill fluid.

Models EJA438W and EJA438N Diaphragm Sealed Gauge Pressure Transmitters can be used to measure liquid, gas or steam pressure. They output a 4 to 20 mA DC signal corresponding to the measured pressure.
The models EJA438W and EJA438N feature remote setup and monitoring through communications with the model BT200/100 BRAIN TERMINAL, CENTUM CS/XL system etc.

Technical parameters of Yokogawa EJA438E Diaphragm Sealed Gauge Pressure Transmitters

Model	Application	Mounting	Capsule Code	Measure Range	Max. Working Pressure
EJA110E	Differential Pressure	Traditional	F M H V	0.5 to 5 kpa 1 to 100 kpa 5 to 500 kpa 0.14 to 14 MPa	16 Mpa 16 Mpa 16 Mpa 16 Mpa
EJA115E	Low Flow	Internal Integral Orifice	F M H	1 to 5kpa 2 to 100 kpa 20 to 210 kpa	16 Mpa 16 Mpa 16 Mpa
EJA118E	Differential Pressure and Level with remote seal	Extended Flush Flange	M H	2.5 to 100 kpa 25 to 500 kpa	Based on Flange Rating
EJA120E	Small Draft Range Differential Pressure	Traditional	E	0.1 to 1 kpa	50kpa
EJA130E	Differential Pressure and Level	Traditional	M H	1 to 100 kpa 5 to 500 kpa	32 Mpa 32 Mpa
EJA210E	Tank liquid level	Extended & Flush Flange	M H	1 to 100 kpa 5 to 500 kpa	Based on Flange Rating
EJA310E	Absolute & vacuum pressure	Traditional	L M A B	0.67 to 10 kpa 1.3 to 130 kpa 0.03 to 3.5 MPa 0.14 to 16 MPa	10 kPa 130 kPa 3.5 Mpa 16 MPa
EJA430E	Gauge Pressure	Traditional	H A B	5 to 500 kpa 0.03 to 3.5 MPa 0.14 to 16 MPa	500 kPa 3.5 Mpa 16 MPa
EJA438E	Gauge Pressure with remote seal	Extended & Flush Flange	A B	0.06 to 3.5 MPa 0.46 to 16 MPa	Based on Flange Rating
EJA440E	High Gauge Pressure measurement	Traditional	C D	5 to 32 MPa 5 to 50 MPa	32 Mpa 50 Mpa
EJA510E EJA530E	Absolute & Gauge Pressure with thread connection	Direct	A B C C	10 to 200 kpa 0.1 to 2 MPa 0.5 to 10 MPa 5 to 50 MPa	200 kpa 2 Mpa 10 Mpa 50 Mpa

Overview of Yokogawa EJA438E Diaphragm Sealed Gauge Pressure Transmitters

Measurement Types
Primary Variable	Gauge Pressure
Reference Accuracy
Primary Variable	±0.2% of Span
Rangeability
Primary Variable	A-Capsule: 50:1 B-Capsule: 30:1 (EJA438W) 8-Capsule: 15:1 (EJA438N)

Yokogawa EJA438E Diaphragm Sealed Gauge Pressure Transmitters

EJA430E-DAS4G-915DJ/HE
EJA430E-DBS4G-717DD/D3 (0-10 Barg)
EJA430E-JAS4G-712EN/FU1/D3
EJA430E-JAS4J-914EJ/KS21/D1
EJA430E-JAS4J-914EJ-KS21/D1
EJA430E-JBS4G-924DJ/KU22/D3/M11/T12

EJA430E-JAH5J-92DDB/FS1/D3
EJA430E-JAH5J-92DDB/FS1/D3
EJA430E-DAS4G-310DD/D4
EJA430E-JAS4J-912DB
EJA430E-JBS5J-919DN/KS21/A1/D3/N4/M01/T12

Yokogawa EJA438E Diaphragm Sealed Gauge Pressure Transmitters

YTA610-JA1A4DD/KU2/A/X2
YTA710-JA1A4DD/KU2

EJA110E-JMH5G-92DDB/FF1/D3
EJA110E-JMS4G-714DD/KU22/X2/M11
EJA110E-JHS4G-724DN/KU22/M11/T12
EJA110E-JHS3G-814DB/KF22
EJA110E-JMS4J-919DB/D4
EJA110E-JVS4G-814DB
EJA110E-JMS4G-814DB
EJA110E-JLH4J-912DB/D4
EJA110E-JMS4J-912EB/KU22/D3/M11
EJA110E-JLH4J-912EB/KU22/D3/M11
EJA110E-JVS4J-912EB/KU22/D3/M11
EJA110E-JMH5G-92DDB/FF1/D3
EJA110E-JMS4J-912DB/N4
EJA110E-DMS3G-917DB/KF22/X2/A/K2/D4
EJA110E-DMS3G-917DB/KF22/A/D4
EJA110E-DLH3G-917DB/KF22/A/D4

EJA110E-JMS4J-92DEB/KS21/D3/C2/N4/M11/T12
EJA110E-JMM4J-92DEB/KS21/D3/C2/N4/M11/T12
EJA110E-JFS4J-92DEB/KS21/D3/C2/N4/M11/T12
EJA110E-JHS4J-92DEB/KS21/D3/C2/N4/M11/T12
EJA110E-JHM4J-92DEB/KS21/D3/C2/N4/M11/T12
EJA110E-JLH5G-919DB/KU22/X2/D4/M01/T12
EJA110E-JMS5G-919EJ/K2
EJA110E-JLH4J-812ED
EJA110E-JMS4J-812ED
EJA110E-JLH4G-912DB/D4
EJA110E-JHA5G-92DEJ/KS21/D3/N4/M01
EJA110E-JMS5G-92DEJ/KS21/D3/N4/M01
EJA110E-JMS5G-92DEJ/KS21/HG/D3/N4/M01
EJA110E-JHS4G-912DB/D4
EJA110E-JMS5G-91DDB/KF22/N4/M01/T12

EJA510E-JAS4N-017DL/D4
EJA510E-JBS4N-019DN/D4
EJA530E-JAS4N-017DL/D4
EJA530E-JDH7N-02DEN/KS21/D3/N4/M15
EJA530E-JBS4N-012EL/KU22/D3/M15
EJA530E-JCS4N-014DL
EJA530E-JCS7N-012DL/D4
EJA530E-JBS7N-012DL/D4
EJA530E-JCS4N-012EL/KU22/D3/M15
EJA530E-DBS4N-017DL/KF22/A/D4
EJA530E-JBS4N-014EL/KS21/D3/C2/N4/M15/T06
EJA530E-JDS4N-014EL/KS21/D3/C2/N4/M15/T08
EJA530E-JCS4N-02DEL/KS21/D3/C2/N4/M15/T07
EJA530E-JDS7N-02DEN/KS21/D3/N4/M15
EJA530E-JBS8N-014DL/KU22/X2/D3
EJA530E-JCS7N-012EL/FS1
EJA530E-JBS7N-024DN/KU22/M15/T06

EJA118E-JMSCG-912DB-YA1WB1SY03-BC2A/D4
EJA118E-JMSCJ-912DB-YA1WA1SY01-BC2A/D4
EJA120E-JES4J-812EB
EJA120E-JES4J-812EB
EJA210E-JMS4G-914DN-WD23C2TW00-B/KU22/X2/M1W
EJA210E-DHS4G-917DN-WA13C1SW00-A
EJA210E-JMS4J-912DN-EA14B1SE01-B/D4

EJX110A-EHS4G-919DB/D4
EJX430A-EBS4G-317DD/FF1/D4/C1/CA/T12
EJX530A-EBS4N-022EL/KS21/D4/N4
