Yokogawa EJA210E-JHS4J-912DN-EJ14A2SE01-B/D4 EJA210E Differential Pressure Transmitter





Place of Origin:Japan

Brand Name:Yokogawa

Model Number:EJA210E

Output Signal:4 to 20 mA DC, 2-wire system with digital communication

Accuracy:±5 % of span

Ambient Temperature Limits:-40 to 85 C (-40 to 185 F) (general-use type)

Mounting:2-inch pipe mounting

Degrees of Protection:IP67, NEMA4X

Capsule gaskets material:Teflon-coated JIS SUS316L

Process connector gasket:PTFE (Teflon)

Amplifier Housing:Cast aluminum alloy or JIS SCS14A stainless steel

Integral Indicator:LCD digital indicator (optional)

General of Yokogawa EJA210E-JHS4J-912DN-EJ14A2SE01-B/D4 EJA210E Differential Pressure Transmitter

The EJA-E series of transmitters is Yokogawa's most recent evolution of the DPharp family of pressure transmitters. Released in 2012, it combines the ruggedness and success of the work-horse EJA-A series with the performance of the thoroughbred EJX-A series to deliver the type of product you have come to expect from Yokogawa.

The EJA210E is the Flange-mount Liquid Level Transmitter in the series.

EJA210E features include:

·  ± 0.075% Accuracy

·  ± 0.1% per 1 year Stability

·  120 msec Response Time

·  Exida and TUV SIL2 / SIL3 Certified

·  Signal Characterizer for the 4 to 20 mA output

·  Local Parameter Setting (LPS)

Yokogawa EJA210E-JHS4J-912DN-EJ14A2SE01-B/D4 EJA210E Differential Pressure Transmitter

The high performance flange mounted differential pressure transmitter EJA210E can be used to measure levels of densities of solidifying or precipitating liquids. EJA210E outputs a 4 to 20 mA DC signal corresponding to the measured differential pressure. Its accurate and stable sensor can also measure the static pressure which can be shown on the integral indicator or remotely monitored via BRAIN or HART communications. Other key features include quick response, remote set-up using communications and self-diagnostics. FOUNDATION Fieldbus, PROFIBUS PA and 1 to 5 V DC with HART (Low Power) protocol types are also available. All EJA-E series models in their standard configuration, with the exception of the Fieldbus, PROFIBUS and Low Power types, are certified as complying with SIL 2 for safety requirement.

Process Connections  of Yokogawa EJA210E-JHS4J-912DN-EJ14A2SE01-B/D4 EJA210E Differential Pressure Transmitter

Key Features of Yokogawa EJA210E-JHS4J-912DN-EJ14A2SE01-B/D4 EJA210E Differential Pressure Transmitter

1) Excellent Performance and Stability  Yokogawa EJA210E-JHS4J-912DN-EJ14A2SE01-B/D4 EJA210E Differential Pressure Transmitter

The EJA series uses a silicon resonant sensor formed from monocrystal silicon, a perfect material which has no hysteresis in pressure or temperature changes. The sensor minimizes overpressure, temperature change, and static pressure effects, and thus offers unmatched long-term stability.

2) Compact and Light-Weight Design  Yokogawa EJA210E-JHS4J-912DN-EJ14A2SE01-B/D4 EJA210E Differential Pressure Transmitter

Half the weight of conventional models thanks to miniaturization of the casing with the amplifier ASIC, pressure cell structure, and flange. The ASIC uses the minimum number of parts and improves the reliability of the amplifier.

3) Fieldbus Communication Capability  Yokogawa EJA210E-JHS4J-912DN-EJ14A2SE01-B/D4 EJA210E Differential Pressure Transmitter

EJA series offers two types of fieldbus models, FOUNDATION™ fieldbus Low Voltage Mode and PROFIBUS PA devices, which ensure interoperability between Yokogawa and other manufactures. As for software, the EJA series incorporates two AI function blocks that compute differential and static pressures to allow flexible configuration of instrumentation.

Yokogawa EJA210E-JHS4J-912DN-EJ14A2SE01-B/D4 EJA210E Differential Pressure Transmitter

Ordering Models of Yokogawa EJA210E-JHS4J-912DN-EJ14A2SE01-B/D4 EJA210E Differential Pressure Transmitter

EJA210E-DMS4G-91CDN-WA13C1SWB0-B/KF22/X2/D3/T52
EJA210E-DMS4G-91CDN-WA13C1SWB0-B/NF2/X2/D3/T52
EJA210E-JHS4G-912EN-EA13B2WE03-B/FU1/D1
EJA210E-JHS4G-912EN-EA13B2WE03-B/NF2/D1
EJA210E-JMS4G-912NN-EA13B1WE03-B/FU1
EJA210E-JMS4G-912NN-EA13B1WE03-B/NF2
EJA210E-JMS3J-912EN-WA13C2HW00-A/D1
EJA210E-DMS4J-912NN-EJ14A2SE01-B/D4
EJA210E-JMS4G-912EN-WA13B2SW00B/FS1/D1
EJA210E-JHS4J-917EN-WD23A2SW00-B/KF22/N4
EJA210E-JHS4J-917EN-WD23A2SW00-B/NF2/N4
EJA210E-JMS4G-912DN-WD23C2SW00-B
EJA210E-JHS4G-912EN-EA13B2WE03-B/FU1/D1
EJA210E-JMS5G-912DN-WA13B2TW00-B
EJA210E-DMS1J-912NN-EA14A1SE01-B
EJA210E-JMS5G-912DN-WA13B1SW00-B
EJA210E-JMS5G-919DN-WD23A2SW00-B
EJA210E-JMS4J-917DN-WA13B1SW00-A
EJA210E-JHS4G-912DN-WA13B2SW00-A
EJA210E-JMS4G-912DN-WA13B2SW00-A
EJA210E-JMS4G-912EN-WA13B2SW00-B/FS1/D1
EJA210E-JHS4G-912DN-WA13B2SW00-A
EJA210E-JHS4G-912DN-WA13B2TW00-A
EJA210E-JMS4J-912DN-EA13A2WE01-B/HE
EJA210E-JMS4G-912EN-EA13B1WE03-B
EJA210E-JMS4G-912EN-EA13B1WE01-B
EJA210E-JMS4G-912NN-WA13A1SW00-B/FS1
EJA210E-JMS4J-912DN-EA14A2SE01-B/HE
EJA210E-JHS5G-912DN-WA13A1SW00-B
EJA210E-JHS4G-92DDN-WA23A1SW00-B/KS21/A/D4/M1W/T56
EJA210E-JHS4G-92DDN-WA23A1SW00-B/KS21/A/D4/M1W/T56
EJA210E-JMS4G-92DDN-WA23A2HW00-B/KS21/A/D4/M1W/T56
EJA210E-JMS4G-92DDN-WA23A1SW00-B/KS21/A/D4/M1W/T56
EJA210E-JMS4G-92DDN-WA23A2HW00-B/KS21/A/D4/M1W/T56
EJA210E-JMS4G-92DDN-WA23A2HW00-B/KS21/A/D4/M1W/T56
EJA210E-JHS4G-92DDN-WA23C1SW00-B/KS21/A/D4/M1W/T56
EJA210E-JMS4G-92DDN-WA23C1SW00-B/KS21/A/D4/M1W/T56
EJA210E-JHS4G-92DDN-WA23C1SW00-B/KS21/A/D4/M1W/T56
EJA210E-JHS4G-92DDN-WA23C1SW00-B/KS21/A/D4/M1W/T56
EJA210E-JMS4G-92DDN-WA23C2HW00-B/KS21/A/D4/M1W/T56
EJA210E-JMS4G-92DDN-WA23C1SW00-B/KS21/A/D4/M1W/T56
EJA210E-JMS4G-92DDN-WA23C2HW00-B/KS21/A/D4/M1W/T56
EJA210E-JMS4G-92DDN-WA23C2HW00-B/KS21/A/D4/M1W/T56
EJA210E-JMS4G-92DDN-WA23C2HW00-B/KS21/A/D4/M1W/T56
EJA210E-JMS4G-92DDN-WA23C2HW00-B/KS21/A/D4/M1W/T56

Yokogawa EJA210E-JHS4J-912DN-EJ14A2SE01-B/D4 EJA210E Differential Pressure Transmitter

EJA110E Differential Pressure Transmitter

EJA115E Low Flow Transmitter

EJA118E Diaphragm Sealed Differential Pressure Transmitter

EJA510E and EJA530E Absolute and Gauge Pressure Transmitter

EJA120E Differential Pressure Transmitter

EJA130E Differential Pressure Transmitter

EJA210E Flange Mounted Differential Pressure Transmitter

EJA310E Absolute Pressure Transmitter

EJA430E Gauge Pressure Transmitter

EJA438E Diaphragm Sealed Gauge Pressure Transmitter

EJA438E/Z Diaphragm Sealed Gauge Pressure Transmitter

EJA440E Gauge Pressure Transmitter
